High Definition Smpte296m Medical Lcd Monitor Display Quick Response Time

High Definition Smpte296m Medical Lcd Monitor Display Quick Response Time

    • High Definition Smpte296m Medical Lcd Monitor Display Quick Response Time
    • High Definition Smpte296m Medical Lcd Monitor Display Quick Response Time
  • High Definition Smpte296m Medical Lcd Monitor Display Quick Response Time

    Product Details:

    Place of Origin: CHINA
    Brand Name: Genevision
    Certification: CE/ROHS/FCC/SGS
    Model Number: MSDI-200

    Payment & Shipping Terms:

    Minimum Order Quantity: 50PCS
    Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
    Delivery Time: 10 working days after received your payment
    Payment Terms: T/T or western Union
    Supply Ability: 3,000pcs per month
    Contact Now
    Detailed Product Description
    Input: AV(BNC) X 2,S-Video X 1,VGA X 1, X1 Contrast Ratio: 1000:1
    Active Area: 408mm(H) X 306mm(V) Responsive Time: 5ms
    Aspect Ratio: 4:3 Resolution: 800x 600
    High Light:

    medical grade lcd monitors

    ,

    medical lcd displays



    High Definition Smpte296m Medical Lcd Monitor Display Quick Response Time

    Description:

    Genevision MSDI broadcast monitor chooses Top project., SDI technology is a high quality image representative of serial transmission, mainly used in some professional field of television and radio and television, the product supports audio embedded solution, at the same time, supports the highest resolution to 1080 p 60 hz, which should be more extensive.

    Performance Features as follows:


    1. Terminal interface: SDI goes  into a conversion for the output signal.
    2. To support HD-SDI, SD - SDI.
    3.The thickness of PCB copper is 2 times of that of general interface card.
    4. All capacitors are tantalum capacitors.
    5. Use BNC VIDEO signal terminal, to prevent loss.
    6. Support the SDI embedded audio
    7,Quick response time(5ms);
    8,Automatic backlight system;
    9,Variety input and output interfaces;
    Support mode list:



     SN

    Mode

    SMPTE

    Type

    1

    1080I @60HZ

    SMPTE260M

    HDTV

    2

    1080I @60HZ

    SMPTE274M

    HDTV

    3

    1080I @50HZ

    SMPTE274M

    HDTV

    4

    1080I @50HZ

    SMPTE295M

    HDTV

    5

    1080P @30HZ

    SMPTE274M

    HDTV

    6

    1080P @25HZ

    SMPTE274M

    HDTV

    7

    1080P @24HZ

    SMPTE274M

    HDTV

    8

    720P @60HZ

    SMPTE296M

    HDTV

    9

    720P @50HZ

    SMPTE296M

    HDTV

    10

    NTSC (480I@60HZ)

    SMPTE267

    SDTV

    11

    576I@50HZ

    ITU-R BT601.5

    SDTV



    PAL-I

    ITU-R BT601.5

    SDTV

    12

    PAL-B,G,H

    ITU-R BT601.5

    SDTV

    13

    PAL-N

    ITU-R BT601.5

    SDTV

    14

    1080P   50HZ



    3G

    15

    1080P   60HZ



    3G

    Note:such mode does not support1080PSF24HZ,1080I48HZ,720P24HZ,720P25HZ,
    720P30HZ.

    Applications:


    Hospital

    Surgery, Laboratory,Testing room

    Entertainment

    Live studio, Film shooting


    Specifications:
    Technical Parameter for LCD Panel

    Model No

    MSDI-200

    Panel Size

    20inch

    Aspect Ratio

    4:3

    Active Area

    408mm(H) x 306mm(V)

    Resolution

    800x 600

    Dot Pitch

    0.51mm(H) x 0.51mm(W)

    Number of Color

    16.7M

    Brightness

    500cd/m2

    Contrast Ratio

    1000:1

    Visual angle

    1780

    Responsive Time

    5ms

    Input

    AV(BNC) X 2,S-Video X 1,VGA X 1, X1
