20 Inch Tft Vesa Cctv Monitor Screen , Wall Mounted Hd Monitor Input

20 Inch Tft Vesa Cctv Monitor Screen , Wall Mounted Hd Monitor Input

    • 20 Inch Tft Vesa Cctv Monitor Screen , Wall Mounted Hd Monitor  Input
    • 20 Inch Tft Vesa Cctv Monitor Screen , Wall Mounted Hd Monitor  Input
    • 20 Inch Tft Vesa Cctv Monitor Screen , Wall Mounted Hd Monitor  Input
  • 20 Inch Tft Vesa Cctv Monitor Screen , Wall Mounted Hd Monitor  Input

    Product Details:

    Place of Origin: GuangDong China
    Brand Name: GENEVISION
    Certification: CE
    Model Number: HJMD-200

    Payment & Shipping Terms:

    Minimum Order Quantity: 50pcs
    Price: 0.1~0.2
    Packaging Details: packing in carton box, plywood, standard packing
    Delivery Time: 2~3 weeks
    Payment Terms: T/T, Western Union
    Supply Ability: 5000pcd/month
    Contact Now
    Detailed Product Description
    Voltage: AC 100V~240V Aspect Ratio: 4:3
    Interface: BNC,VGA, Resolution: 800×600
    Install: Wall Mounted/ Computer Standing Dot Pitch: 0.51(H)×0.51(V)
    High Light:

    medical lcd panel

    ,

    medical lcd displays





    20 Inch Tft Vesa Cctv Lcd Monitor , Wall Mounted Hd Monitor Input



    Description:

    1. Ultra-slim design,convenient use,delicate appearance.
    2. Industrial A+ grade LCD panel
    3. High contrast,High brightness,vivid image layout,bets details performance.
    4. Auto eliminate blur function,long life span.
    5. Auto adjust VGA image reproduction rate.
    6. Multiple date-image adjustment circuit,low image distortion.
    7. Intelligence temperature control fan design,green and quiet.
    8. Wide visual angle 178°,aspect ratio 4:3
    9. Rich signal input,output interfaces,adapted in the different environments.
    10. Appling the latest 3D digital image decode chipset,the latest DNR,image clear,clean and vivid.
    11. Intensive the IR receiver,support the IR remote to modify the monitor parameters.
    12. Build-in stable power,low consumption,long life span>60000hours

    Applications:



    Stock exchanges, Traffic control centers, Airports, media centers, military systems, public space, shopping areas, banks, schools, hospitals, special circumstances etc.



    Specifications:



    Technical Parameter for LCD Panel

    product

    20" HD LCD Monitor

    model

    MJHD-200

    Screen type

    20" TFT LCD

    Display area

    408(W)×306(H)

    Aspect ratio

    16:9

    resolution

    800×600

    Number of colors

    16.7M

    Dot pitch

    0.51(H)×0.51(V)

    brightness

    500cd/㎡

    contrast

    1000:1

    Viewing angle

    178°/178°

    Response time

    5ms

    HF

    31k~68kHZ

    VF

    56~75HZ

    color system

    PAL/NTSC/SECAM

    Signal interface

    Input:2*BNC,1*VGA,,1*,1*AUDIO output:1*BNC

    voltage

    AC  100V~240V

    On mode

    ≤50W

    Standby model

    ≤3W

    Working temperature

    0°~50°

    humidity

    20%~80%

    Life

    60000H

    color

    Black/white/customized

    installment

    Desktop/wall mounted

    certification

    CE/3C/FCC/UL

    Dimension

    435×353×69.5

    Net weight

    8.5KG





    Competitive Advantage:



    Wide voltage range,AC 110V~240V,industrial grade design,can be used in harsh environment.
