High Definition SMPTE296M Medical LCD Monitor Display SDI embedded audio

Product Details

Place of Origin: China

Brand Name: GENEVISION

Certification: CE

Model Number: MSDI-200

Payment & Shipping Terms

Get Best Price
Product Details
Highlight:

medical lcd panel

,

medical lcd displays

Working Temperature & Humidity:
00C~400C/10%~90%
Color System:
PAL/NTSC/SECAM
Power Supply:
100 -240V AC
Input:
AV(BNC) X 2,S-Video X 1,VGA X 1, X1,DVI X 1(optional)
Panel Size:
20inch
Aspect Ratio:
4:3
Working Temperature & Humidity:
00C~400C/10%~90%
Color System:
PAL/NTSC/SECAM
Power Supply:
100 -240V AC
Input:
AV(BNC) X 2,S-Video X 1,VGA X 1, X1,DVI X 1(optional)
Panel Size:
20inch
Aspect Ratio:
4:3
Product Description





High Definition SMPTE296M Medical LCD Monitor Display SDI embedded audio

Description:

Genevision MSDI broadcast monitor chooses Top project., SDI technology is a high quality image representative of serial transmission, mainly used in some professional field of television and radio and television, the product supports audio embedded solution, at the same time, supports the highest resolution to 1080 p 60 hz, which should be more extensive.

Performance Features as follows:
1. Terminal interface: SDI goes  into a conversion for the output signal.
2. To support HD-SDI, SD - SDI.
3.The thickness of PCB copper is 2 times of that of general interface card.
4. All capacitors are tantalum capacitors.
5. Use BNC VIDEO signal terminal, to prevent loss.
6. Support the SDI embedded audio
7,Quick response time(5ms);
8,Automatic backlight system;
9,Variety input and output interfaces;
Support mode list:

 SN

Mode

SMPTE

Type

1

1080I @60HZ

SMPTE260M

HDTV

2

1080I @60HZ

SMPTE274M

HDTV

3

1080I @50HZ

SMPTE274M

HDTV

4

1080I @50HZ

SMPTE295M

HDTV

5

1080P @30HZ

SMPTE274M

HDTV

6

1080P @25HZ

SMPTE274M

HDTV

7

1080P @24HZ

SMPTE274M

HDTV

8

720P @60HZ

SMPTE296M

HDTV

9

720P @50HZ

SMPTE296M

HDTV

10

NTSC (480I@60HZ)

SMPTE267

SDTV

11

576I@50HZ

ITU-R BT601.5

SDTV



PAL-I

ITU-R BT601.5

SDTV

12

PAL-B,G,H

ITU-R BT601.5

SDTV

13

PAL-N

ITU-R BT601.5

SDTV

14

1080P   50HZ



3G

15

1080P   60HZ



3G

Note:such mode does not support1080PSF24HZ,1080I48HZ,720P24HZ,720P25HZ,
720P30HZ.
Applications:


Hospital

Surgery, Laboratory,Testing room

Entertainment

Live studio, Film shooting


Specifications:
Technical Parameter for LCD Panel

Model No

MSDI-200

Panel Size

20inch

Aspect Ratio

4:3

Active Area

408mm(H) x 306mm(V)

Resolution

800x 600

Dot Pitch

0.51mm(H) x 0.51mm(W)

Number of Color

16.7M

Brightness

500cd/m2

Contrast Ratio

1000:1

Visual angle

1780

Responsive Time

5ms

Input

AV(BNC) X 2,S-Video X 1,VGA X 1, X1,DVI X 1(optional)

Output

AV(BNC) X 1

Power supply

100 -240V AC

Color system

PAL/NTSC/SECAM

Power consumption

≤50W

Panel Life

above 50000 hours

Working Temperature & Humidity

00C~400C/10%~90%

Certificate

3C/FCC/CE/ROHS/UL


Competitive Advantage:

Genevision endoscope & surgical Medical LCD Monitor,adopts high definition LCD panel and wide visual angle to meet the needs of today’s medical display,can observe clearly the exact surgery position and elaborate operation in minimally invasive surgery(MIS).White frame,waterproof design,antimicrobial treatment,compliance with electromagnetic compatibility requirements,a variety of video input and output interfaces,making the product fully comply with endoscope and operating room,ICU display requirements.
