Product Details
Place of Origin: CHINA
Brand Name: Genevision
Certification: CE/ROHS/FCC/SGS
Model Number: MG-260ANW-D
Payment & Shipping Terms
Minimum Order Quantity: 50PCS
Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Time: 10 working days after received your payment
Payment Terms: T/T or western Union
Supply Ability: 3,000pcs per month
Screen: |
26inch |
Aspect: |
16:9 |
Dot Pitch: |
0.421mm(H) X 0.421mm(W) |
Brightness: |
500cdm2 |
Contrast: |
1000:1 |
Color Number: |
16.7M |
Keyword: |
Digital Wall Display |
Screen: |
26inch |
Aspect: |
16:9 |
Dot Pitch: |
0.421mm(H) X 0.421mm(W) |
Brightness: |
500cdm2 |
Contrast: |
1000:1 |
Color Number: |
16.7M |
Keyword: |
Digital Wall Display |
Specifications:
|
Technical Parameter for LCD Panel |
Panel Size |
26inch real color LCD screen |
|
Aspect Ratio |
16:9 |
|
|
Active Area |
575.6mm(H) x 323.6mm(V) |
|
|
Max. Resolution |
1366x 768 |
|
|
Dot Pitch |
0.421mm(H) x 0.421mm(W) |
|
|
Number of Color |
16.7M |
|
|
Brightness |
500cd/m2 |
|
|
Contrast Ratio |
1500:1 |
|
|
Responsive Time |
8ms |
|
|
Panel Life |
above 50000 hours |
|
|
Storage Medium |
Flash memory card |
2gb to 36gb for the capacity |
|
Support Ad files |
Video formats |
MP4(AVI:DIVX/XVID),MPG2(DVD:VOB/MPG2), MPEG1 (VCD: DAT/MPG1) |
|
Audio formats |
MP3 |
|
|
Photo formats |
JPG |
|
|
OSD Language |
English, Chinese, French, German, Italian, Spanish,Arabic |
|
|
Audio output |
stereo L/R, 5W*2, 8Ω |
|
|
Power supply |
AC 110V - 240V, 50/60HZ |
|
|
Storage Temperature |
-7 to 65 Celsius degree |
|
|
Normal Working Temperature |
-5 to 65 Celsius degree |
|
Description:
1,network player with 10/100M Ethernet,can download media contents from local server and managed by media server software.
2,Shell is made of high quality hardware
3,Can be installed in advertising program flow subtitles, flows in a broadcast subtitles.
4, Easy to set auto download time frame and auto download media contents from the media server..
5,Media server software supports playlist editor and scheduling to send playlist to multiple groups of network players.
6,Create group and player ID/play/stop/volume setting/open and close video output/
reboot/close/format SD card/send text note/send playlist/send command of auto loading and play/display SD card status, capacity and filename.
7,Software to update ads file for the machine.
8,Server farm set up in the head-quaters network management center adopting advanced B/S management structure to handle ,control , monitor all kinds of broadcasting media of information and release various multimedia information.
9,Through managing the allocation of users and the division of corresponding limits of authority or signing in the server management center ,we can control the long-distance terminal of DMB ,distributed real time executive and publish financial data ,multimedia information ,controlling information ,programme guide,in the meanwhile,we upload and issue the sub-account ,verify the master account to achieve the management of simple division of labor.
10,Support the user-defined split screen.it can add as many as 8 screen elements (time .date.picture,video,financial information ,subtitle ) and free to change the position ,size and frame of the screen elements.
11,Grouping management ,aiming at playing distinct content of different sales network and using zone to enhance the pertinence of information
12,Fixed-time download:setting the downloading time of source program (like seating 00:00 to 6:00 a.m),which would make the best of idle network source as well as ensure the normal use of main tractions
13,Onboard watch-dog design that realizes the automatic recovery when the devices malfunction
14,Level-2 review of broadcasting content and supervision by technical means to prevent the control of system from the illegal users and ensure the legality of information to the public.
15,Server can connect with the broadband in static or dynamic setting assuring the salability of broadband
16,Manage it at any time or any where without restraint of IP address and regions
17,Real-time checking on the broadcasting content of terminal
18, Real-time interception of network information such as stocks ,exchange rate ,weather
Applications:
|
Business Organizations |
supermarket, large-scale shopping malls, exclusive agency, chain shops, large-scale sales, star-rated hotels, restaurants, travel agencies, pharmacy. |
|
Financial Organizations |
Banks, negotiable securities, funds, insurance companies, pawnshops; |
|
Public Places |
subway, airports, stations, gas stations, toll stations, bookstores, parks, exhibition halls, stadiums, museums, convention centers, ticket agencies, HR market, lottery centers; Real Estate Property: Apartments, villas, offices, commercial buildings, model rooms, property brokers; |
|
Entertainments |
Movie theaters, fitness halls, country clubs, clubs, massage rooms, bars, cafes, Internet bars, beauty shops, golf course |
Competitive Advantage:
Server farm set up in the head-quaters network management center adopting advanced B/S management structure to handle ,control , monitor all kinds of broadcasting media of information and release various multimedia information.Through managing the allocation of users and the division of corresponding limits of authority or signing in the server management center ,we can control the long-distance terminal of DMB ,distributed real time executive and publish financial data ,multimedia information ,controlling information ,programme guide,in the meanwhile,we upload and issue the sub-account ,verify the master account to achieve the management of simple division of labor.
LCD AD player,LCD Media Player,LCD AD Board.
