Wall Mounted Waterproof Digital Signage 43 Inch Hd 1080P Fan Cooling IP65 2000cd

Product Description

43inch wall mounte outdoor LCD digital signage fan cooling advertising screen

1. Structure:
According to the enclosure protection class GB4208-93, the protection level of the integrated chassis and constant temperature system used in this equipment will reach the IP55 full outdoor equipment standard and be designed according to the following principles:
(1) The outer casing is made of 1.5mm SGCC galvanized steel plate and sprayed with AkzoNobel outdoor special plastic powder for more than 10 years.
(2) The outer shell structure is designed to be waterproof and the inlet and outlet air holes are waterproof, which meets the IP55 protection level.
3) Dust-proof design: The special air-dust filter is specially designed for the air inlet and outlet. It filters the dust in the air and prevents mosquitoes from entering the machine. It is easy to disassemble and design, which is convenient for customers to maintain regularly.
(4) The protective glass of the front screen of the whole machine adopts 6mm AR glass, the light transmittance is ≥97%, high light transmission and anti-reflection.
(5) The whole machine adopts the front and rear door opening mode, which can conveniently repair the internal display, heat dissipation components and electronic components.
(6) The whole machine adopts modular design, which is convenient for installation and maintenance.
(7) The design hole of the bottom plate of the whole machine can be fixed by the explosion bolt or the pre-embedded threaded rod.

2. LCD Display:
(1) Adopt LG industrial grade high brightness liquid crystal display, the brightness reaches 2000cd/m2.
(2) High resolution, high contrast, high brightness, greatly improving the layering of the picture, and better performance details.
(3) It has the function of automatically eliminating the residual image, UV protection, heat insulation for the sun, and automatic light-sensing green energy-saving protection for long-term use of the LCD screen.
(4) It has a black level extension adaptive function to enhance the image depth of field.
(5) Adopting the outdoor professional high-brightness LCD screen, the video image is more beautiful and the stereoscopic effect is stronger.
(6) 16.7M color, the picture is more natural, and the delicate picture is really no tailing.
(7) Long life, 7*24 hours of uninterrupted work, up to 50,000 hours.
3. Electrical:
(1) Electrical protection: leakage, overload, overvoltage protection, lightning protection device, over temperature protection, etc.
(2) Audio: It adopts two-channel, stereo surround power amplifier system, and the output power is 8 ohms and 10W.
(3) Working environment temperature design standard +50 ° ~ -30 °.
(4) Adopt modular design principles, sustainable and maintainable design.
(5) Automatic sensitization adjustment: The screen backlight adopts automatic ambient light sensing, which adjusts the brightness of the screen in real time to meet the clear image display under the strong direct sunlight environment, and makes the screen not glare at night, saving energy and environmental protection.
4. Heat dissipation:
(1) It adopts integrated intelligent direct ventilation and cooling system, specializing in special air duct heat dissipation design.
(2) The internal air and the external air of the whole machine are cyclically exchanged. After the external air enters the dust-proof net for filtering, it is divided into two wind circulations after the screen front screen to ensure the internal temperature reaches a temperature difference of 8-10 degrees from the external temperature.
(3) Independently research and develop the fan speed control board, which can automatically adjust the fan speed according to the internal temperature of the machine.
(4) Configure high-temperature automatic power-off protection function. When the internal temperature of the machine is abnormally high temperature and exceeds the normal working range, the control system will protect the main components such as the display from power-off protection. At the same time, the fan continues to run at full speed to fully protect the display and the main Parts.
