CCC 46 Inch 3.5mm Narrow Bezel DID LCD Video Wall
Product Details:
| Place of Origin: | China |
| Brand Name: | Genevision |
| Certification: | CE, CCC |
| Model Number: | MTD-460 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 2pc |
|---|---|
| Price: | USD580 per unit |
| Packaging Details: | Honeycomb carton reinforced by wooden box |
| Delivery Time: | 10 working days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 3000pc per month |
|
Detail Information |
|||
| Screen Size: | 46inch Transparent DID Screen | Brightness: | 500cd/m2 |
|---|---|---|---|
| Application: | Shopping Mall Advertising Video Wall | Bezel: | 3.5mm Narrow Bezel |
| Installtion: | Wall-mount Or Floorstanding Cabinet | Color: | Black |
| High Light: | 3.5mm Bezel DID LCD Video Wall,CCC Narrow Bezel LCD Video Wall,46 Inch Narrow Bezel Video Wall |
||
Product Description
46inch Extreme Narrow Bezel 3.5mm LCD Video Wall Build In Controller Board
LED glass screen is latest and marvelous of optoelectronic screen. This screen based on glass, on the premise of ensure see-through transparency, implemented super array full color image.
No need additional structure, only need installed on the glass wall directly.
Unique Advantage:
1. Next-generation LCD video wall system with built-in video wall processing
2. 46” or 55” extreme narrow bezel LCD video wall with tiled bezel width as small as 0.88 mm
3. Software for simplified installation, monitoring and management
Integrated technology eliminates video tearing and delivers genlock synchronization
4. ultra slim screen fram ultra thin body design
5. can be displayed horizontally or vertically
6. Indoor maintenance, fast and safe. No need outdoor maintenance, to save more cost.
7. High brightness.
| Specification: | |||||
| Specification | MD-460 | Panel Size | 46"LED | ||
| Panel brand | Original BOE A level | ||||
| Aspect Ratio | 16:9 | ||||
| Visual Angle | Horizontal 178/Vertical178 | ||||
| Brightness | 500cd/sqm | ||||
| Bezel | 3.5 mm | ||||
| Back light | LED backlight | ||||
| Contract Ratio | 3500:1 | ||||
| Resolution Ratio | 1920*1080 | ||||
| Color Components | 16.7M | ||||
| Response Time | 8ms | ||||
| Power Consumption | 120W/150W | ||||
| Standby power consumption | 10W | ||||
| Power Supply | Input:AC110-220V-50/60Hz | ||||
| Life of Panel | 60000Hours | ||||
| Frame size (±1mm) | (Width)1020.88mm*(Height)575.49mm | ||||
| Size of Shell Frame(±1mm) | Left /right side1.9mm/top/bottom1.9mm | ||||
| Panel Display Area | (Width)1018.08mm*(Height)572.69mm | ||||
| Port | 2*BNC(video in/out), 1*VGA in, 1*DVI in,1* in, 1*RS232 in, 2*RS232 out, 1*Debug ISR | ||||
| VGA/DVI Resolution Ratio | 640*480,800*600,1024*768,1280*1024,1600*1200,1920*1080 | ||||
| Resolution Ratio | 480I,480P,576I,720P,1080I,1080P | ||||
| Split Screen/PIP Mode | Two signals image or PIP | ||||
| Splice Function | Multiscreen Splice Function(image processing Function) | ||||
| Carton Packing | 2pc/carton, carton size: 114*34*70cm, G.W.: 47kg | ||||
| Wooden box packing | 4cartons(8pc)/wooden box, wooden box size: 122*145*85cm, G.W.: 105kg | ||||
| Bracket carton packing | 174*12*25cm, G.W.: 29kg | ||||
Why choose us:
1. 14-years professional manufacturing experience only in digital signage field.
2. LCD display projects from 8" to 108' in various brightness can be tailor-made according to your specific requirements.
3. Rich experience in OEM and ODM projects in more than 10 years.
4. Less MOQ can meet your various requirements.
5. Fast delivery time, sample needs 10-15days, bulk needs 15-20days, have stock of standard item.
6. Flexible Payment term: support T/T, L/C, Westunion, Paypal.
7. Shipments: Internation express, airfreight, oceanfreight.
8. Warranty: 1-year warranty, lifetime maintenance.
