24" Touch Screen Floor Standing Outdoor Self Order Payment Kiosk Machine with QR Scanner Thermal Printer POS Terminal with Door Bell
Product Overview
Floor Standing Self-Ordering Kiosk with QR Scanner & Printer, Restaurant Digital Menu Order Terminal
Quick Details of outdoor self service kiosk
- 24" IPS panel in 1920*1080 resolution.
- Outdoor IP65 waterproof and in commercial grade.
- Has 80mm thermal printer, QR code scanner and POS holder for buyer to install their own POS locally.
- System can be Android 11.0, 12.0, 13.0, 14.0 or Win 10 or 11 IOT.
- Color can be white or black.
- Logo printing support.
- 10 points PCAP touch screen.
- Has 1500nits high brightness and air cooling fans inbuilt.
Technical Specifications of outdoor waterproof self payment terminal
| Item |
Details |
| Display |
24" IPS panel, resolution 1920*1080, brightness 1500cd/m², contrast 1000:1, view angle 178°/178°(H/V) |
| Display Area |
531.36(W)×298.89(H) mm |
| Color |
16.7M |
| Response Time |
Approximately 8 ms |
| Service Life |
> 50000 hours |
| Power Supply |
DC12V (±10%), power consumption 14W |
| CPU |
RK3288, RK3566, RK3568, RK3576, T972, T982, RK3399 |
| RAM |
DDR3 / 4 2G, 4G, 8G |
| Memory |
32G, 64G, 128G |
| Internet Connection |
Wifi, RJ45 |
| System |
Android 11.0, 12.0, 13.0, 14.0 |
| QR Code Scanner |
Built-in, high-precision, fast scanning speed |
| Printer |
Built-in thermal printer, automatic receipt printing |
| Speaker |
2.5W/4R, voice broadcast support |
| Interfaces |
OTG*1, USB HOST*1, RS232*1, Relay output*1 |
| Installation |
Floor-standing, height adjustable; optional wall-mounted design |
| Shell Material |
Aluminum+Metal, industrial grade, waterproof and dustproof |
| Working Temperature |
0℃~60℃ |
| Storage Temperature |
-20℃~45℃ |
| Multilingual Support |
27 languages including English, Japanese, German, French, Spanish, etc. |
| Additional Functions |
Attendance record (optional), menu remote update, order data query, secondary development support |
| Carton Dimension |
To be confirmed |
| Touch Type |
Optional |
| Deployment Model |
Support public cloud deployment, privatized deployment, LAN use, stand-alone use |
Applications
- Fast food restaurants and quick-service restaurants (QSR), such as chain stores, improving ordering efficiency and reducing queuing time
- Food courts in shopping malls, supermarkets and office buildings, providing self-service ordering services for multiple catering stalls
- Cafes, milk tea shops and dessert stores, facilitating customers to order and pay independently, reducing staff workload
- Restaurants in tourist scenic spots, airports, railway stations and subway stations, serving domestic and foreign customers with multilingual support
- Chain restaurants and large-scale catering institutions, realizing unified menu management and order data statistics
- Corporate canteens and school canteens, facilitating staff and students to order and pick up meals quickly, improving dining efficiency
RFQ
1.What is a self-service kiosk?
A self-service kiosk is an interactive touchscreen terminal that allows customers to independently access information, purchase products, or complete tasks without staff assistance. These devices, equipped with specialized software, combine digital convenience with physical service to streamline operations across various industries.
2.How They Work
Kiosks consist of a physical screen device—such as a floor stand, wall mount, or countertop tablet—running a restricted interface called "kiosk mode". Users independently navigate menus, input data, and complete secure payments using integrated card readers, mobile wallets, or cash acceptors.
3.Common Use Cases
You interact with self-service kiosks daily across multiple sectors:
Retail: Self-checkout registers, price checkers, and endless-aisle ordering.
Restaurants: Fast-food ordering systems where you can customize your meal and pay independently.
Travel & Hospitality: Airport check-in desks, hotel keycard dispensers, and movie theater ticket purchases.
Services & Admin: Post office parcel weighers/stamp dispensers, bank ATMs, and hospital/clinic check-in desks.
Wayfinding: Interactive maps and directories in malls and corporate buildings.
4.Benefits
Businesses and consumers alike utilize these systems for several key advantages:
Shorter Wait Times: Reduces lines during peak hours by spreading transactions across multiple terminals.
Greater Accuracy: Minimizes human error since customers directly input their own data or modify their food orders.
Increased Revenue: Built-in software can intuitively suggest upsells or additional items, driving up average transaction sizes.
Operational Efficiency: Frees up staff to focus on customer service, food preparation, or other high-value tasks.
5.What is the difference between a vending machine and a kiosk?
Smart vending machines process transactions and dispense physical products immediately, while kiosks facilitate transactions or information access without physical product delivery. This key distinction drives cascading differences throughout the design, implementation, operation, and application of these technologies.
Outdoor self service payment kiosk core features:
1. Rugged & Weatherproof DesignEnvironmental Resistance:
Built with heavy-duty steel and anti-corrosive coatings. They feature an IP65 or IP66 rating to protect internal hardware against torrential rain, dust, and airborne debris.Temperature Control: Equipped with internal HVAC systems, thermostats, and cooling fans to prevent overheating in extreme heat or freezing in the cold.Vandal Resistance: Utilizes shatterproof, anti-glare, and vandal-resistant touch glass with reinforced locking mechanisms to prevent tampering.
2. High-Visibility DisplaysSunlight Readability:
Features ultra-bright screens (typically 2,500+ nits) with auto-dimming sensors to ensure clear legibility even in direct, bright sunlight.Intuitive UI/UX: Designed with simple, multi-lingual, and highly responsive touch interfaces to guide users effortlessly through transactions.
3. Diverse Payment ProcessingContactless & Mobile:
NFC/RFID readers to process tap-to-pay options like Apple Pay, Google Pay, and digital wallets.EMV Card Readers: Secure chip and PIN or swipe readers for standard credit and debit cards.Cash & Coin Handling: Optional modules for bill acceptors, coin acceptors, and recyclers to allow cash transactions.
4. Advanced Hardware PeripheralsBarcode & QR Scanners:
To instantly read digital or printed tickets, passes, vouchers, and bills.Thermal Printers: For on-demand issuance of receipts, tickets, or parking passes.Accessibility Features: Audio jacks, voice recognition, and lowered UI placements for ADA or equivalent accessibility compliance.
5. Security & ConnectivityRobust Encryption:
Features secure, PCI-compliant and EMV-certified POS integrations to protect user data against fraud.Remote Monitoring: Cloud-based management systems allow operators to monitor terminal health, process live transactions, and check cash levels in real time.Connectivity: Supports encrypted, secure connections via 4G/5G cellular routers, Wi-Fi, or hardwired Ethernet.
