24 Inch IP65 Waterproof Outdoor Touch Screen Kiosk with 15000 Nits High Brightness and 316 Stainless Steel Housing

Name: 24 Inch IP65 Waterproof Outdoor Touch Screen Kiosk with 15000 Nits High Brightness and 316 Stainless Steel Housing
Brand: Shenzhen MercedesTechnology Co., Ltd.
SKU: MOAD-240
Price: 1865 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Genevision

Certification: CE, FCC, ROHS, CCC

Model Number: MOAD-240

Payment & Shipping Terms

Minimum Order Quantity: 1PC

Price: 1865$/Unit

Packaging Details: Carton reinforced by plywood box

Delivery Time: 10-15working days

Payment Terms: T/T,Paypal,Western Union

Supply Ability: 3000piece/month

Get Best Price

Product Details

Product Description

Product Details

Highlight:

Product Name:	24 Inch Outdoor Waterproof Touch Screen Kiosk \| IP65 Stainless Steel Self Service Terminal With Metal Keyboard RFID	Built In Accessories:	RFID Reader And Integrated Keypad
Resolution:	1920×1080	Installation:	Floor Standing
Touch Screen:	10 Point PCAP Touch Screen	System:	Android Or PC
Scanner:	RFID	Brightness:	1500cd/m²
Power Consumption:	24W	Touch Type:	10-point PCAP Touch Screen
Working Temperature:	0°C - 50°C	Storage Temperature:	-20°C - 60°C

Product Name:	24 Inch Outdoor Waterproof Touch Screen Kiosk \| IP65 Stainless Steel Self Service Terminal With Metal Keyboard RFID
Built In Accessories:	RFID Reader And Integrated Keypad
Resolution:	1920×1080
Installation:	Floor Standing
Touch Screen:	10 Point PCAP Touch Screen
System:	Android Or PC
Scanner:	RFID
Brightness:	1500cd/m²
Power Consumption:	24W
Touch Type:	10-point PCAP Touch Screen
Working Temperature:	0°C - 50°C
Storage Temperature:	-20°C - 60°C

Product Description

24 Inch Outdoor Waterproof Touch Screen Kiosk | IP65 Stainless Steel Self Service Terminal with Metal Keyboard RFID

IP65 Outdoor Self Service Kiosk 24 Inch 15000nits High Brightness Touch Kiosk with Metal Keyboard & RFID Cutouts. This 24-inch horizontal outdoor touch screen kiosk adopts 316 spray-painted stainless steel enclosure with IP65 waterproof & corrosion-proof performance, stably working in -20℃~45℃ harsh outdoor environments. Equipped with 15000 nits ultra-high brightness LCD panel + AR anti-reflection glass and built-in ambient light sensor for automatic brightness adjustment, the 10-point capacitive touch screen supports clear operation under direct sunlight. Matched with industrial waterproof metal keyboard and reserved RFID installation holes, this outdoor self-service kiosk is widely applied for outdoor access control registration, park inquiry, community self-service and public information query, easy to disassemble and maintain for long-term outdoor deployment.

Key Features

IP65 Waterproof & 316 Stainless Steel Housing
15000 Nits High Brightness Screen + AR Glass
Auto Light Sensor Dimming + Capacitive Touch
Waterproof Industrial Metal Keyboard
Custom RFID Cutouts & Wide Temp Adaptation

Display Specifications

Specification	Details
Resolution	1920×1080
Panel	BOE original panel, A grade
Display Area	518*324mm
Brightness	1500cd/m²
Number of Colors	16.7M
Response Time	8ms (approximately)
Contrast Ratio	1000:1
Viewing Angle	189°/189° (H/V)
Lifetime	> 50,000 hours
Power Supply	AC 110V~240V, 50/60Hz
Power Consumption	24W
Shell Material	Aluminum + Metal
Touch Type	10-point PCAP touch screen
Working Temperature	0°C - 50°C
Storage Temperature	-20°C - 60°C

Android System Configuration

Component	Specification
CPU	RK3568 Quad-core Cortex-A17 2.0GHz
Network Connection	LAN, WiFi
RAM	DDR3 2GB
Memory	32GB
Operating System	Android 11.0, supports Google Play
Interfaces	HDMI out×1, USB×4, LAN×1, VGA×1

Windows System Configuration

Component	Specification
CPU	i3, i5, i7
Network Connection	LAN, WiFi
Memory	DDR3 4GB or 8GB
SSD	128GB or 256GB
Operating System	Windows
Interfaces	HDMI out×1, USB×4, LAN×1, VGA×1

Frequently Asked Questions

What is the waterproof rating of this outdoor touch screen kiosk?

Our 24-inch outdoor touch kiosk reaches IP65 standard waterproof grade. The whole cabinet uses sealed structural design together with 316 stainless steel shell, effectively blocking rainwater, dust and moisture invasion to adapt to outdoor rainy, dusty weather conditions.

Can the high brightness screen be used normally in direct sunlight outdoors?

Yes. The display is 15000 nits high brightness LCD with AR coated anti-reflection tempered glass, paired with a light sensor to auto dim screen brightness according to ambient light. Users can view the screen content clearly even under strong direct sunlight.

What material is the cabinet of this outdoor self-service kiosk made of?

The kiosk housing is made of spray-painted 316 stainless steel material. It features strong corrosion resistance, anti-rust performance and long service life, suitable for coastal, humid and other corrosive outdoor scenarios.

What functions does the integrated metal keyboard support on the outdoor kiosk?

The embedded industrial metal keyboard is waterproof and dustproof, designed for outdoor long-term frequent manual input operations such as account password entry, information filling and data query, with wear-resistant keys for stable long-time usage.

What working temperature range can this outdoor self-service terminal withstand?

The whole machine works stably within the temperature range of -20°C to 45°C. The internal heat dissipation structure avoids overheating in high-temperature summer, and internal components support normal startup and operation in low-temperature cold winter outdoors.

Customization Options

Full OEM and ODM services available including screen size variations, shell color customization, card reader integration, printer functionality, camera, and additional hardware features.
