43 Inch PCAP Touch Screen Digital Kiosk Display With 2D QR Scanner

43 Inch PCAP Touch Screen Digital Kiosk Display With 2D QR Scanner

Product Details:

Place of Origin: China
Brand Name: Genevision
Certification: CE CCC ROHS
Model Number: MAD-430

Payment & Shipping Terms:

Minimum Order Quantity: 1PC
Price: USD500-USD1000/ unit
Packaging Details: Standard export carton reinforced by wooden box
Delivery Time: 10-15 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 3000pc per month
Get Best Price Contact Now

Detail Information

Key Word: Touch Screen All In One Kiosk Screen Size: 15.6inch To 65inch
Certificate: FCC, ROHS, CE, CCC Touch Screen: Yes, 10 Points
Color: Black/White Application: Hotel Office Reception Desk, Exhibition Center, Retail Shop, Shopping Mall, Library, Airport
OEM: Support Touch Screen: IR Or PCAP Touch
Inbuilt: NFC/Printer/2D Scanner Installation: Wall Mout Or Floor Standing
High Light:

PCAP Touch Screen Digital Kiosk Display

,

43 Inch Digital Kiosk Display

,

Touch Screen Kiosk With QR Scanner

Product Description

43" Digital Floor Stand PCAP Touch Screen Kiosk Inbuilt Printer 2D QR Scanner


Quick details digital touch screen display:



1. Various size optional from 15.6inch to 65inch.

2. Wall mount or with floor stand optional,mostly landscape screen viewing

3. 10 point interactive touch screen,have IR touch and capacity touch two option

4. Metal case black or white colour

5. 5MM temperared glass on front

6. Inbuilt hardware can be choose:NFC,IC/ID card reader,Thermal printer,2D scanner

7. System can be Android 7.1 OS or Windows 10 Pro

8. Can working 7/24 hours,life time 5000 hours

9. OEM/ODM are welcome to contact us,we are the direct manufacturer on touch screen totem



Specification of touch screen ticket machine :



Panel size 43"  (15.6" to 65" optional)
Resolution 1920*1080
Panel brand BOE, AUO etc. A level
Display area 476*268mm
Brightness 250cd/m2 to 400 cd/m2
Number of Color 16.7M
Response time 8 (ms) approximately
Contrast 1200:1
View angle 178°/178°(H/V)
Life Time > 50000 (hours)
Power Supply AC 110V~240V,50/60HZ
Power Consumption 40W - 180W
Photo Formats JPEG ,BMP ,GIF ,PNG
Audio Formats MP3,WAV,WMA
Video Format MP4,AVI,DIVX,XVID,VOB,DAT,MPG,MPEG,RM,RMVB,MKV,MOV,HDMOV,M4V
Shell Material Aluminum+Metal
Bare diemension TBC
Wooden box dimension TBC
Thermal printer Inbuilt
Touch Type 10-point capacitive touch screen
NFC card reader Optional
QR code scanner Optional
Thermal printer Optional
Normal Working Temperature 0°——50°
Normal Storage Temperature -20°——60°
Accessory Power Cable, Allen key
OSD Language English, Chinese, French, German, Italian, Spanish,Arabic etc.



CPU RK3288 Quadcore Cortex-A17 1.8GHz
Network connection LAN, WIFI
RAM DDR4 2G
Memory 16G
The operating system Android 7.1, 9.0, support Google Play
Interface HDMI out*1, USB*1, USB OTG*1, Lan*1, SD card*1



CPU I3, I5, I7
Network connection LAN, WIFI
Memory DDR3 4G, 8G
SSD 128G, 256G
The operating system Windows 10
Interface HDMI out*1,USB *4 ,LAN *1, VGA*1


Description of self service touch screen kiosk:



This lcd touch screen kiosk are widely use for several years in public place, but we've developed this model by inbuilt several components to meet different client's requirement,you can call it as self checking information kiosk.



Hot sale size 32" to 55",common is 2K resolution,we also can do 4K for your order.

For touch screen,common is IR touch screen 10 points,but more and more client requirement capacitive touch screen,which is more sensitive.

The screen right side inbuilt with some parts,can choose thermal printer 80mm or 58mm paper,Card reader support NFC,IC,ID card.

Or 2D scanner,support QR code or Bar Code.Support designated brands,such as quality brand Zebra or Motorola.



As we always can provide, system can be Android, Windows, Ubuntu or Linux as per customer's request, call specification can be met at reasonable cost.



For shipping, we suggest pack in playwood box to protect LCD monitor, for order of hundreds units, screen can be in  honeycomb carton and put into container directly.




Application of all in one PC kiosk with scanner :



This touch screen ticket dispenser kiosk can be put in hotel reception desk and bank for people to check information or waiting for their turn, also the self service touch screen kiosk can be put in library and exhibition center, besides, the touch screen payment kiosk can be put in shopping mall for POS terminal.


43 Inch PCAP Touch Screen Digital Kiosk Display With 2D QR Scanner 0

43 Inch PCAP Touch Screen Digital Kiosk Display With 2D QR Scanner 1

43 Inch PCAP Touch Screen Digital Kiosk Display With 2D QR Scanner 2



Real picture of 43" digital podium kiosk with printer in our factory:



43 Inch PCAP Touch Screen Digital Kiosk Display With 2D QR Scanner 3
